Description

Support for multi-screen synchronous playback and synchronous and asynchronous modes makes this multimedia player a perfect fit for a wide range of applications. Thanks to its reliability, ease of use, and intelligent control, the TB60 becomes a winning choice for commercial LED displays and smart city applications such as fixed displays, lamp-post displays, chain store displays, advertisement players, mirror displays, retail store displays, door head displays, shelf displays, and much more.

‍

Features

‍‍

Output

- Loading capacity up to 1,300,000 pixels

Maximum width: 4096 pixels

Maximum height: 4096 pixels

- 2x Gigabit Ethernet ports

All these four ports serve as primary by default. Users can also set two as primary and the other two as backup.

- 1x Stereo audio connector

The audio sample rate of the internal source is fixed at 48 kHz. The audio sample rate of the external source supports 32 kHz, 44.1 kHz, or 48 kHz. If NovaStar’s multifunction card is used for audio output, audio with a sample rate of 48 kHz is required.

- 1x HDMI 1.4 connector

Maximum output: 1080p@60Hz, support for HDMI loop

‍

Input

- 1x HDMI 1.4 connector

In synchronous mode, video sources input from this connector can be scaled to fit the entire screen automatically.

- 2x Sensor connectors

Connect to brightness sensors or temperature and humidity sensors.

‍

Control

- 1x USB 3.0 (Type A) port

Allows for USB playback and firmware upgrade over USB.

- 1x USB (Type B) port

Connects to the control computer for content publishing and screen control.

- 1x Gigabit Ethernet port

Connects to the control computer, a LAN or public network for content publishing and screen control.

‍
